Tissue Culture Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-10378
Quick Answer: The Tissue Culture Microscope pairs a 45 degree inclined Siedentopf trinocular head with phase contrast annular spots and a 1X C-mount adapter. Illumination is a 6 V 20 W halogen lamp with adjustable brightness.
Last updated: November 2026
Key Features
Optical system with F = 180 mm.
Siedentopf trinocular head inclined at 45 degrees.
6 V 20 W halogen illumination with adjustable brightness.
Condenser N.A. 0.35, WD 45/102 mm.
WF10X/20 mm and WF16X/13 mm eyepieces, plus a 10X/18 mm reticle eyepiece with 0.1 mm scale.
Phase contrast annular spots for 10X, 25X and 40X.
Technical Specifications
| Specification | Value |
|---|---|
| Optical system | F = 180 mm |
| Viewing head | Siedentopf trinocular, 45 degree inclined |
| Illumination | Halogen 6 V 20 W, adjustable brightness |
| Condenser | N.A. 0.35 (WD 45/102 mm) |
| Adapter | C-mount 1X |
| Eyepieces | WF10X/20 mm, WF16X/13 mm, reticle 10X/18 mm with 0.1 mm scale |
| Phase contrast annular spots | 25X; 10X, 25X, 40X |
About This Product
With phase contrast annular spots for several magnifications and a reticle eyepiece carrying a 0.1 mm scale, the microscope covers both observation and measurement in tissue culture work. The trinocular head and 1X C-mount adapter add a third port alongside the binocular eyepieces.
Frequently Asked Questions
Which eyepieces are provided?
WF10X/20 mm and WF16X/13 mm eyepieces, plus a reticle eyepiece of 10X/18 mm with a 0.1 mm scale.
What phase contrast annular spots are listed?
A phase contrast annular spot of 25X, and phase contrast annular spots of 10X, 25X and 40X.
What illumination does it use?
A 6 V 20 W halogen lamp with adjustable brightness.
Which consumables go with the Tissue Culture Microscope?
Cultures are kept and viewed in dishes and flasks; a Rack For Petri Dishes stores Petri dishes, and samples can be stored in Storage Vial or Cryo Vial vials for storage down to -190 degrees C.
Why use an inverted microscope like the Tissue Culture Microscope?
The objectives sit below the stage and the light comes from above, so cells can be viewed through the base of a culture flask or dish without opening it or disturbing the sample.
Related: Microscopes, Inverted Tissue Culture Microscope, Trinocular Inverted Tissue Culture Microscope.
For a quotation on the Tissue Culture Microscope, contact Educational Lab Equipments.
