LED Cordless Dual View Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-11012
Quick Answer: The LED Cordless Dual View Microscope has a dual view head with two locked-on 10x wide-field eyepieces, one with a pointer, so two people can look at the same slide.
Last updated: November 2026
Key Features
Dual view head, 45 degree inclined, 360 degree rotatable, with two locked-on 10x wide-field eyepieces (one with pointer).
Glass achromatic 4x, 10x and 40x objectives – parfocal, parcentred, colour-coded.
Reverse three-position nosepiece with positive click stops.
Cordless LED illumination with on/off switch; NiMH batteries and power adapter both included.
3.5 inch round movable stage with locked-on spring-loaded clips; 6-hole rotating disc diaphragm.
All-metal frame, 12 inches tall; coarse focus knob with built-in slip clutch.
Technical Specifications
| Specification | Value |
|---|---|
| Head | Dual view, 45 degrees, 360 degree rotation |
| Eyepieces | 2 x 10x wide-field, locked-on (1 with pointer) |
| Objectives | 4x, 10x, 40x glass achromatic |
| Nosepiece | Reverse, 3 positions, click stops |
| Stage | 3.5 inch round, movable |
| Diaphragm | 6-hole rotating disc |
| Power | NiMH batteries or adapter, both included |
| Height | 12 inches |
About This Product
With two eyepieces on one head, two viewers can study the same specimen at once, and the pointer in one eyepiece helps pick out details. The cordless LED runs from NiMH batteries or the adapter included with it, and the six-hole disc diaphragm adjusts the light reaching the slide.
Frequently Asked Questions
Can two people use the LED Cordless Dual View Microscope at the same time?
Yes. The dual view head carries two locked-on 10x wide-field eyepieces, one fitted with a pointer, so two viewers can see the same specimen.
How is it powered?
The cordless LED illumination runs on NiMH batteries or a power adapter; both are included.
How can images from the LED Cordless Dual View Microscope be recorded or shared?
A Digital Eyepiece Camera connects to a computer over USB, and the Universal Smartphone Optics Adapter holds a phone on the eyepiece. For measurement work, calibrate with a Stage Micrometer.
Who is the LED Cordless Dual View Microscope suited to?
Laboratories and teaching departments that need to share or record what is seen, for example when one teacher demonstrates to a group, or when images are kept for reports and practical records.
Related: Microscopes, LED Cordless Beginner Monocular Microscope, Digital Camera Microscope with Dual View, Cordless Compound Monocular Microscope.
For a quotation on the LED Cordless Dual View Microscope, contact Educational Lab Equipments.
