Coaxial Trinocular Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-10983
Quick Answer: The Coaxial Trinocular Microscope has an inclined trinocular head, an Abbe N.A. 1.25 condenser and a built-in 6 V–20 W halogen light, with coarse and fine focusing from a single coaxial knob.
Last updated: October 2026
Key Features
Inclined trinocular head; body rotatable through 360 degrees.
Coaxial graduated mechanical stage moving the slide up to 50 x 75 mm.
Abbe N.A. 1.25 condenser, focusable by rack and pinion through 25 mm, with iris diaphragm and swing-out filter holder.
Built-in base halogen illumination, 6 V–20 W, with on/off switch and intensity regulator.
Plano-concave reflector set for daylight use.
Single coaxial focusing knob on a four-step gear reduction system.
Technical Specifications
Specification
Value
Head
Inclined trinocular
Stage
Coaxial graduated mechanical, X-Y travel up to 50 x 75 mm
Condenser
Abbe N.A. 1.25, rack and pinion, 25 mm travel
Illumination
Built-in halogen, 6 V–20 W, intensity regulator
Daylight option
Plano-concave reflector
Focusing
Single coaxial knob, four-step gear reduction
About This Product
One coaxial knob drives both coarse and fine focus through a four-step gear reduction, giving a smooth action. The halogen lamp in the base is dimmed with its own regulator and comes with power cord and plug, while the plano-concave reflector set lets the microscope work by daylight.
Frequently Asked Questions
How does focusing work on the Coaxial Trinocular Microscope?
Coarse and fine focus are both worked from a single coaxial knob, which runs on a four-step gear reduction system.
Is there a daylight option?
Yes. Besides the built-in 6 V–20 W halogen source with intensity regulator, a set of plano-concave reflectors is provided for working in daylight.
