Medical Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-10373
Quick Answer: The Medical Microscope magnifies small objects from 20x to 1500x, using 10x, 45x and 100x oil immersion objectives on a quadruple revolving nosepiece. Its stand inclines through 90 degrees and carries a 120 x 120 mm fixed square stage with a mechanical stage.
Last updated: November 2026
Key Features
Magnification 20x to 1500x.
Stand inclinable through 90 degrees; mechanical tube length 160 mm.
Separate knobs for coarse and fine focusing.
Fixed square stage 120 x 120 mm with mechanical stage, 30 x 76 mm travel, graduated scales and vernier.
Plano-concave mirror on a gimbal mount, with an optional attachable lamp.
Huygenian 5x or 15x and WF 10x eyepieces.
Technical Specifications
| Specification | Value |
|---|---|
| Magnification | 20x to 1500x |
| Stand | Inclinable through 90 degrees |
| Mechanical tube length | 160 mm |
| Focusing | Separate coarse and fine knobs |
| Stage | Fixed square, 120 x 120 mm; mechanical stage 30 x 76 mm travel with scales and vernier |
| Illumination | Plano-concave mirror on gimbal mount; optional 20 W lamp for 220 V, or 6 V 20 W with transformer |
| Nosepiece | Quadruple revolving |
| Objectives | 10x, 45x, 100x oil immersion |
About This Product
The microscope is used in medical labs to magnify images of small objects, with the 100x oil immersion objective used at the top of its range. Light is directed by a plano-concave mirror on a gimbal mount, and an attachable lamp can be added as an option.
Frequently Asked Questions
What objectives are fitted?
10x and 45x objectives with a 100x oil immersion objective, on a quadruple revolving nosepiece.
What lighting options are available?
A plano-concave mirror on a gimbal mount is standard; an attachable 20 W lamp for 220 V, or a 6 V 20 W lamp with transformer, is optionally available.
What is the stage size?
A fixed square stage of 120 x 120 mm with a mechanical stage that travels 30 x 76 mm, with graduated scales and vernier.
What else is useful with the Medical Microscope in a college or clinical lab?
A Stage Micrometer for calibrating the eyepiece scale, prepared slides such as Artery, Vein & Nerve (400x) and Bacteria (1000x, gram stain), and a Slide Holder for storing slides.
How should the Medical Microscope be cleaned and stored?
Switch off and let the lamp cool, wipe oil from the 100x objective with lens tissue, lower the stage, set the lowest-power objective in place and fit the dust cover.
