Product Code : EL-WWM-11720
Quick Answer: The Portable Planer is a power planer for the woodworking shop, driven by a 6.5 Amp motor at 16,500 rpm no-load speed, with a ratcheting knob that sets depth from 0 to 3/32 inch (2.6 mm) within one revolution.
Last updated: October 2026
Key Features
6.5 Amp motor with a no-load speed of 16,500 rpm for fast stock removal and a smooth finish.
Ratcheting depth knob covering 0 to 3/32 inch (2.6 mm) in one revolution, with no need to re-zero.
Chip ejection that can be directed to the left or the right.
Two-blade system that can be converted to take large high-speed steel blades.
Bevel guide fence for consistent planing from 0 to 45 degrees, with a shield over the unused part of the blade.
Spring-loaded park rest and an ambidextrous lock-off release button.
Technical Specifications
| Specification | Value |
|---|---|
| Motor | 6.5 Amp |
| No-load speed | 16,500 rpm |
| Depth adjustment | 0 to 3/32 inch (2.6 mm), ratcheting knob |
| Bevel range | 0 to 45 degrees |
| Blades | 2-blade system, convertible to large high-speed steel blades |
About This Product
The ratcheting knob covers its whole depth range within a single revolution, so the planer never has to be re-zeroed between settings. Shavings can be thrown to whichever side suits the bench, and the bevel fence holds the angle steady along the full length of a workpiece. When the tool is put down, the spring-loaded park rest protects both blade and work, and its shape also lets a cut begin partway along a piece. Educational Lab Equipments can supply and export the Portable Planer to Saint Vincent and the Grenadines, Democratic Republic of the Congo, Kyrgyzstan, Gabon, Malta and Kazakhstan.
Frequently Asked Questions
What depth settings does the Portable Planer offer?
The ratcheting depth knob sets increments from 0 to 3/32 inch (2.6 mm) within one revolution, so there is no need to re-zero the depth.
Can it plane bevels?
Yes. The bevel guide fence gives consistent planing from 0 to 45 degrees through the whole workpiece, and a protective shield covers the part of the blade not in use.
Which blades does it use?
It has a two-blade system and can be converted for use with large high-speed steel blades.
