Triaxial Test Set Manufacturer,Supplier and Exporter in India
Product Code : EL-SM-11922
Quick Answer: Sized for soil specimens up to 70 mm in diameter, the Triaxial Test Set provides the cell and accessories for unconsolidated undrained, consolidated drained, consolidated undrained and unconfined compression tests. It includes a pedestal, drained top cap, aluminium base plate, porous discs, membranes, O-rings, filter drains and a split mould.
Last updated: October 2026
Key Features
Triaxial cell for specimens up to 70 mm diameter, with matching pedestal and top cap with drainage.
Aluminium base plate and a set of 2 porous discs for 70 mm specimens.
Rubber latex membrane and neoprene O-ring for 70 mm (2.8 in) specimens.
Suction sleeve stretcher for 70 mm, 2.8 in and 3 in specimens.
Filter drains in a pack of 50 and a two-part split mould.
Covers UU, CD, CU and UC test types.
Technical Specifications
Specification
Value
Test types
UU, CD, CU, UC
Specimen diameter
Up to 70 mm (2.8 in)
Base plate
Aluminium
Porous discs
Set of 2
Membrane
Rubber latex
O-ring
Neoprene
Filter drains
Pack of 50
Mould
Two-part split mould
About This Product
A specimen shaped in the two-part split mould is drawn into a latex membrane with the suction sleeve stretcher, sealed with neoprene O-rings and set on the pedestal under the drained top cap. Every component, from the base plate to the porous discs, is matched to the one 70 mm specimen size.
