Surface Treatment Plant Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11260
Quick Answer: The Surface Treatment Plant carries the load by jib crane through 5 stations on the Y axis – chemical oil cleaning, rinsing, acid dipping, rinsing and zinc coating – and lifts or lowers it between 2 positions on the vertical axis.
Last updated: October 2026
Key Features
Chemical oil cleaning station with a temperature-controlled bath, regulated by wave-train control and static relays.
Rinsing, acid dipping and acid zinc plating stations.
Jib crane moved on the Y and Z axes by horizontal and vertical translation motors at about 0.2 m/s.
Electrolytic zinc plating bath fed from a 0–10 A controlled direct current generator, with voltage and current display.
Transparent guard over the working area, ventilation hood, retention tank and filtering block.
Electrical cabinet for the plant controls.
Technical Specifications
| Specification | Value |
|---|---|
| Y axis positions | 5 (oil cleaning, rinsing, acid dipping, rinsing, zinc coating) |
| Z axis positions | 2 (high and low) |
| Handling speed | About 0.2 m/s on Y and Z |
| Plating current | 0–10 A, controlled DC |
| Oil cleaning bath control | Wave-train with static relays |
| Displays | Voltage and current |
About This Product
The plant reproduces a small zinc plating line, and students manage both the crane positions and the bath conditions of a real coating sequence. Each load is cleaned in the temperature-controlled chemical oil bath, rinsed, dipped in acid, rinsed again and then zinc coated in the electrolytic bath, whose current is set on the controlled DC generator and read on the display. The Surface Treatment Plant can be dispatched from India to Côte d'Ivoire, Laos, Somalia, Serbia and Sudan.
Frequently Asked Questions
Which process steps does the plant cover?
Five positions on the Y axis handle chemical oil cleaning, rinsing, acid dipping, a second rinsing and zinc coating, while the jib crane moves between high and low positions on the vertical axis.
How is the zinc plating bath powered?
From a current generator delivering 0–10 A of controlled direct current, with the voltage and current shown on a display.
How fast does the jib crane move?
It travels on the horizontal Y axis and vertical Z axis at about 0.2 m/s, driven by separate horizontal and vertical translation motors.
