Whirling Of Shaft Apparatus Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11385
Quick Answer: The Whirling Of Shaft Apparatus spins a shaft with a 1/16 HP, 6500 RPM DC motor under dimmerstat control so students can find the critical (whirling) speed at which the shaft resonates.
Last updated: October 2026
Key Features
Driving motor: 230V DC, 1/16 HP, 6500 RPM.
Shaft speed controlled by a 240v, 2 amp, 50 cycle dimmerstat.
Used to find the critical speeds at which the shaft whirls.
Technical Specifications
Specification
Value
Motor
230V DC, 1/16 HP
Motor speed
6500 RPM
Speed control
Dimmerstat, 240v, 2 amp, 50 cycles
About This Product
When the shaft speed brings the forcing frequency into line with the natural frequency of the system, resonance sets in. The speed at which this happens is the critical speed, also known as the whirling or whipping speed, and the dimmerstat lets students approach it gradually.
Frequently Asked Questions
What is a whirling speed?
It is the speed at which resonance occurs, when the natural frequency of the system coincides with the frequency of the external forcing. It is also called the critical or whipping speed.
How is shaft speed controlled?
A dimmerstat rated 240v, 2 amp, 50 cycles controls the speed of the 230V DC, 1/16 HP driving motor.
