Microwave Trainer Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11311
Quick Answer: The Microwave Trainer works in the 2.4–2.5 GHz band, using FSK modulation at 4800 to 14400 bps for file transfer and data transmission. Its microwave devices include a low noise amplifier, a Wilkinson power divider, 2.4 GHz and 2.5 GHz band pass filters and an RF amplifier.
Last updated: October 2026
Key Features
FSK modulation and demodulation in the microwave band.
File transfer and data transmission experiments.
Low noise amplifier with 26 dB gain and 2.5 dB noise figure.
2-way Wilkinson power divider and edge-coupled band pass filters.
RF amplifier with 15 dB gain; transmitting and receiving antennas.
Covers micro strip line theory, microwave device basics, measurement, design and simulation.
Technical Specifications
| Specification | Value |
|---|---|
| Frequency band | 2.4–2.5 GHz |
| Output power | +4.5 dBm max |
| Impedance | 50 ohm |
| Modulation | FSK |
| Bit rate | 4800–14400 bps |
| PCB | 0.508 mm thick, dielectric constant 3.38 |
| Low noise amplifier | Gain 26 dB, noise figure 2.5 dB |
| Power divider | 2-way Wilkinson; return loss 14 dB, insertion loss 0.5 dB |
| Band pass filters | 2.4 GHz and 2.5 GHz edge-coupled; return loss 10 dB, insertion loss 7.0 dB |
| RF amplifier | Gain 15 dB, input -5 dBm |
About This Product
Beyond sending data, the trainer is used to study how microwave components are designed and measured: students start from micro strip line theory, then work with the amplifiers, divider and filters as real devices, including experiments in their manufacture and simulation. Transmitting and receiving antennas complete a working communication link.
Frequently Asked Questions
What frequency does the Microwave Trainer use?
It operates in the 2.4 GHz to 2.5 GHz band with FSK modulation and a bit rate of 4800 to 14400 bps.
Which microwave devices are on the trainer?
A low noise amplifier, a 2-way Wilkinson power divider, edge-coupled band pass filters at 2.4 GHz and 2.5 GHz, an RF amplifier and transmitting and receiving antennas.
What PCB is used for the devices?
The PCB is 0.508 mm thick with a dielectric constant of 3.38.
Related: Electronics Engineering Lab Equipments, Microwave Communication Trainer, Digital Signal Processor Trainer.
For a quotation on the Microwave Trainer, contact Educational Lab Equipments.
