Industrial Frequency Converter 3-Phase Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11412
Quick Answer: The Industrial Frequency Converter 3-Phase is a microprocessor-controlled drive of 750 W (1.5 kVA) giving a variable three-phase output of 0–1000 Hz under V/f or vector control.
Last updated: October 2026
Key Features
Linear or quadratic V/f characteristic control, or vector control.
Integrated PID controller, brake transistor and protective functions.
4 parameter sets, set from the LCD operating unit or with the included parameter software.
Connectable fieldbus modules for CAN and Profibus DP, plus a system interface for other bus systems.
Input 3 x 320–550 V, 50/60 Hz; output 0–1000 Hz, 0–2 A.
Technical Specifications
| Specification | Value |
|---|---|
| Nominal power | 750 W, 1.5 kVA |
| Input voltage | 3 x 320–550 V, 50/60 Hz |
| Output voltage | Three-phase, 0 up to input voltage |
| Output frequency | 0–1000 Hz |
| Output current | 0–2 A |
| Control modes | Linear/quadratic V/f or vector control |
| Parameter sets | 4 |
About This Product
Students can drive a motor through linear and quadratic V/f characteristics and vector control, keep different set-ups in the four parameter sets and use the integrated PID controller for closed-loop tasks. The CAN and Profibus DP modules connect the converter to a fieldbus when networked drives are part of the course. Educational Lab Equipments can supply and export the Industrial Frequency Converter 3-Phase to Yemen, Turkey, Syria, Oman and Lebanon.
Frequently Asked Questions
What are the input and output ratings?
Input is 3 x 320–550 V at 50/60 Hz. The output runs from 0 up to the input voltage at 0–1000 Hz and 0–2 A, for a nominal power of 750 W (1.5 kVA).
How are the parameters set?
From the LCD operating unit or with the parameter setting software, which is included. Four sets of parameters are available.
Which bus systems can it join?
Fieldbus modules for CAN and Profibus DP can be connected, and a system interface is provided for alternative bus systems.
