Air Conditioning Unit Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11278
Quick Answer: The Air Conditioning Unit is a computer-controlled teaching duct, transparent and 200 mm x 200 mm, that takes air through preheat, steam humidifying, cooling and dehumidifying, and reheat stages.
Last updated: October 2026
Key Features
Transparent 200 x 200 mm duct for full visibility of the process.
Variable speed fan, flow straightener, preheat elements, steam humidifier, evaporator of an integral refrigeration unit and reheat elements.
4 sets of temperature and relative humidity sensors along the process, plus an electronic air flow sensor.
USB computer control with software for data logging, real-time graph plotting, mimic diagrams and psychrometric chart calculations.
Steam boiler with dual control: a fast heat-up setting and a gentle setting.
Condensate from the evaporator housing collected in an external vessel; mains voltage monitored for heater power calculation.
Technical Specifications
| Specification | Value |
|---|---|
| Duct | Transparent, 200 mm x 200 mm |
| Stages | Preheat, humidifier, chiller/dehumidifier, reheat |
| Measurements | 4 sets of temperature and RH; electronic air flow |
| Interface | USB, with educational software |
| Boiler control | Fast heat-up and gentle settings |
About This Product
Air drawn in by the fan is warmed, humidified by steam from a nozzle, cooled in the evaporator – where moisture condenses and drains to an external vessel – and warmed again before leaving through a louvred exit. With sensors at the inlet and after each stage, the software turns the readings into psychrometric calculations, and the monitored mains voltage allows effective heater powers to be calculated. The Air Conditioning Unit can be dispatched from India to Brunei, Solomon Islands, Mauritania, Peru and Uganda.
Frequently Asked Questions
Where are temperature and humidity measured on the Air Conditioning Unit?
At the air inlet, after the preheat and humidifier, after the evaporator and after the reheat – 4 sets of temperature and relative humidity readings in all.
What does the software do?
It controls the unit over USB and provides data logging, real-time graph plotting and mimic diagrams, and it replicates psychrometric chart calculations. RH sensor calibration values can be entered into it.
Where are the boiler and refrigeration parts fitted?
Under the duct: the steam boiler for the humidifier, the compressor and condenser of the refrigeration system, and the electronic control box.
