Pallet Storage System Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11259
Quick Answer: The Pallet Storage System is a three-element palletising trainer, 1000 x 600 x 510 mm and 68 kg, running on 220 V single-phase power and 6 bar compressed air.
Last updated: October 2026
Key Features
Three elements for a progressive approach to palletising: a bag switching functional chain, a bag configuration and orientation subset, and a module.
Practical work on sensors, pre-actuators, actuators, effectors and mechanical links.
Introduction to automatics, with exercises that follow the program sequences.
5 operative tasks shown and analysed in S.A.D.T. form.
Cycle described by GRAFCET and GEMMA.
Needs 220 V AC single-phase electricity and compressed air at 6 bar.
Technical Specifications
Specification
Value
Dimensions (L x W x H)
1000 x 600 x 510 mm
Mass
68 kg
Electricity
220 V AC, single phase
Compressed air
6 bar
Analysis
5 operative tasks in S.A.D.T. form; cycle in GRAFCET and GEMMA
About This Product
Bags pass through a switching chain and then a subset that arranges and orients them, so each stage can be studied on its own before the whole palletising cycle is run. Students work through the program sequences, identify the sensors, pre-actuators and effectors involved, and read the cycle in GRAFCET and GEMMA.
Frequently Asked Questions
What utilities does the Pallet Storage System need?
A 220 V AC single-phase electricity supply and compressed air at 6 bar.
How is the cycle documented for students?
The cycle is described in GRAFCET and GEMMA, and the system shows 5 operative tasks analysed in S.A.D.T. form.
What does the unit cover in practical work?
Sensors, pre-actuators, actuators, effectors, mechanical links and an introduction to automatics, built up progressively across its three elements.
