Linear Unit Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11413
Quick Answer: The Linear Unit is a toothed-belt linear axis with 700 mm to 800 mm of travel, run together with a synchronous servo system for motion control work.
Last updated: October 2026
Key Features
Toothed belt drive with a belt tightening mechanism.
Overall length of travel 700 mm to 800 mm.
Guide rails protected against damage from mechanical impact.
Integrated end switches with normally open and normally closed contacts.
Built to avoid damage even if invalid parameters are entered for the end limit switches.
Coupled with a synchronous servo system, the two operating together.
Technical Specifications
Specification
Value
Drive
Toothed belt, with tightening mechanism
Travel
700 mm to 800 mm
End switches
Integrated, NO and NC contacts
Servo
Synchronous servo system, coupled
Guide rails
Protected against mechanical impact
About This Product
Paired with its synchronous servo system, the unit gives students a working axis on which to set up positioning moves, end limits and drive parameters. Because the mechanics tolerate a wrong limit-switch entry, mistakes made while learning to configure the axis do not damage the unit. Educational Lab Equipments can supply and export the Linear Unit to Lesotho, South Korea, Estonia, Chile and Saudi Arabia.
Frequently Asked Questions
What kind of drive does the Linear Unit use?
A toothed belt drive with a tightening mechanism, coupled with a synchronous servo system so the two operate together. Overall travel is 700 mm to 800 mm.
What happens if wrong end-limit values are entered?
The unit is built to prevent damage even when invalid parameters are input for the end limit switches. Its integrated end switches have normally open and normally closed contacts.
