Facsimile Dynamic Demonstrator Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11298
Quick Answer: The Facsimile Dynamic Demonstrator is a working desktop fax transceiver in a metal cabinet, scanning with a contact image sensor and printing thermally. It connects to the public switched telephone network, and its modem falls back automatically from 9600 to 7200, 4800 and 2400 bps.
Last updated: October 2026
Key Features
Contact image sensor for horizontal scanning; stepper motor for intermittent vertical scanning.
Thermal printing, 216 mm recording width.
Documents from 70 x 120 mm up to 216 mm x 1 m, 0.06–0.15 mm thick.
Horizontal resolution 8 dots/mm; vertical 3.85 lines/mm standard or 7.7 lines/mm fine.
MH coding; modem speeds of 9600/7200/4800/2400 bps with automatic fall-back.
Housed in a metal cabinet; mains operated.
Technical Specifications
| Specification | Value |
|---|---|
| Type | Desktop transceiver |
| Scanning | Contact image sensor (horizontal), stepper motor (vertical) |
| Printing | Thermal |
| Document size | 70 x 120 mm to 216 mm x 1 m |
| Document thickness | 0.06–0.15 mm |
| Recording paper | 216 mm x 15 m roll, 40 mm outer diameter |
| Resolution | 8 dots/mm; 3.85 or 7.7 lines/mm |
| Modem speed | 9600/7200/4800/2400 bps, auto fall-back |
| Power consumption | 6 W standby, 90 W max |
| Humidity | 45–85% |
About This Product
Rather than explaining fax transmission only on paper, the demonstrator lets students send and receive documents over a telephone line and follow each stage: scanning the page, coding it with the MH scheme, passing it through the modem and printing the received copy. Standard and fine vertical modes show how resolution changes the result. Colleges and TVET centres in Guinea-Bissau, Niger, Eritrea, Mauritania, Saint Vincent and the Grenadines and Bahamas can source the Facsimile Dynamic Demonstrator from Educational Lab Equipments.
Frequently Asked Questions
Which telephone line does the Facsimile Dynamic Demonstrator use?
It is made for the public switched telephone network and works as a desktop transceiver.
What document sizes can it handle?
Documents from 70 x 120 mm up to 216 mm by 1 m, with a thickness of 0.06 to 0.15 mm.
What power does it need?
It is mains operated on a single phase supply, listed for 180–260 V AC at 50/60 Hz, and draws 6 W on standby and up to 90 W.
Related: Electronics Engineering Lab Equipments, ATM Demonstrator, Oscilloscope Demonstrator Trainer.
For a quotation on the Facsimile Dynamic Demonstrator, contact Educational Lab Equipments.
