Frequency Counter Trainer Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11301
Quick Answer: The Frequency Counter Trainer measures from 20 Hz to 30 MHz and shows the result on a 4-digit, 7-segment LED display. Accuracy is +/-(0.5% + 1 digit) of reading, with 0.5 V sensitivity.
Last updated: October 2026
Key Features
20 Hz to 30 MHz measurement range.
Resolution 10 Hz on the 60 kHz range and 10 kHz on the 30 MHz range.
0.5 V input sensitivity.
1:1 and 1:20 input attenuation, AC coupled.
Accepts up to 200 V (DC + AC peak).
4-digit 7-segment LED display.
Technical Specifications
Specification
Value
Frequency range
20 Hz – 30 MHz
Resolution
10 Hz (60 kHz range); 10 kHz (30 MHz range)
Sensitivity
0.5 V
Accuracy
+/-(0.5% + 1 digit) of reading
Attenuation
1:1, 1:20
Input coupling
AC
Max input voltage
200 V (DC + AC peak)
Display
4-digit, 7-segment LED
About This Product
Students apply a signal, choose the attenuation and range, and read the frequency directly, seeing how resolution changes with range: 10 Hz steps on the lower range and 10 kHz steps when measuring up to 30 MHz. It also serves as a working counter for checking the frequency of signal sources in the lab. Educational Lab Equipments can supply and export the Frequency Counter Trainer to Indonesia, Vietnam, Mali, Mozambique and Uganda.
Frequently Asked Questions
What frequency range does the Frequency Counter Trainer cover?
It measures from 20 Hz to 30 MHz, with 10 Hz resolution on the 60 kHz range and 10 kHz resolution on the 30 MHz range.
What is the maximum input voltage?
200 V, counting DC plus AC peak. Input coupling is AC, with 1:1 or 1:20 attenuation.
