Inductive Load Banks Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11227
Quick Answer: An inductive load bank made of three-phase choke coils connected in star, varied by changing the air gap and read through a voltmeter and ammeter.
Last updated: October 2026
Key Features
Three-phase choke coils with copper conductor, connected in star.
Load varied on the air-gap variation principle.
Coils vacuum pressure impregnated for high insulation strength.
High grade silicon stampings.
Voltmeter and ammeter for reading voltage and current at variable loads.
Trolley-mounted, powder-coated MS box.
Technical Specifications
Specification
Value
Configuration
3-phase choke coils in star
Conductor
Copper
Core
High grade silicon stamping
Load variation
Air-gap variation
Insulation
Vacuum pressure impregnated coils
Housing
Powder-coated MS box on trolley
About This Product
Opening or closing the air gap of the choke coils changes their inductance, so the load can be stepped across a range while the voltmeter and ammeter show the voltage and current at each setting. The coils and meters are carried in a powder-coated MS box on a trolley that can be moved around the lab.
Frequently Asked Questions
How is the load varied on the Inductive Load Banks?
They work on the principle of air-gap variation: changing the air gap of the choke coils changes the load, and the voltmeter and ammeter show voltage and current at each setting.
How are the coils insulated?
The wound coils are vacuum pressure impregnated for high insulation strength.
