Coaxial Binocular Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-10377
Quick Answer: The Coaxial Binocular Microscope has a binocular head inclined at 45 degrees with 55 to 75 mm interpupillary and diopter adjustment, above a 115 x 125 mm rectangular stage with a coaxial mechanical stage. Variable 6 V 20 W halogen lighting is built into its box-type base.
Last updated: October 2026
Key Features
Binocular head inclined at 45 degrees.
Interpupillary distance 55 mm to 75 mm, with diopter adjustment.
Rectangular 115 x 125 mm stage with coaxial mechanical stage.
Box-type base with variable 6 V 20 W halogen illumination.
Rack and pinion sub-stage Abbe condenser, N.A. 1.25, with iris diaphragm and filter.
Achromatic objectives 4x, 10x, 40x and 100x (SL).
Technical Specifications
Specification
Value
Head
Binocular, 45 degree inclined
Interpupillary distance
55 to 75 mm, diopter adjustment
Stage
Rectangular 115 x 125 mm, coaxial mechanical stage
Illumination
6 V 20 W halogen, variable, box-type base
Condenser
Abbe, N.A. 1.25, rack and pinion, iris and filter
Objectives
Achromatic 4x, 10x, 40x, 100x (SL)
Eyepieces
Huygenian 5x (pair), WF 10x (pair)
About This Product
Intended for schools, colleges and research institutes, the microscope adjusts to each viewer through its interpupillary and diopter settings. The four achromatic objectives run from 4x up to 100x, and the variable halogen lamp with an iris-equipped condenser lets the light be set for each one.
Frequently Asked Questions
Which objectives are included?
Achromatic objectives of 4x, 10x, 40x and 100x (SL).
Which eyepieces are supplied?
A pair of 5x Huygenian eyepieces and a pair of 10x WF eyepieces.
What is the interpupillary range?
The binocular head adjusts from 55 mm to 75 mm and also has diopter adjustment.
