Dimension Saw Machine Manufacturer,Supplier and Exporter in India
Product Code : EL-WWPT-11692
Quick Answer: The Dimension Saw Machine combines a 3000 x 320 mm sliding table with a 300 mm main blade on a 3 kW motor and a separate 120 mm scoring saw. Its heavy-duty saw carriage sits in a large cast-iron cradle.
Last updated: October 2026
Key Features
Heavy-duty saw carriage seated in a large cast-iron cradle.
Easy-glide sliding table with a heavy-duty quick-release cross-cut fence.
Handwheels for blade height and blade tilt, with a simple index showing the tilt angle.
Scoring saw with manual adjustment, including +/- direction.
Simple overhead saw guard.
Technical Specifications
Specification
Value
Sliding table
3000 x 320 mm
Width of cut to rip fence
1250 mm
Main blade diameter
300 mm (250–300 mm)
Height of cut
80 mm with 300 mm blade
Main spindle
30 mm, 4000/6000 rpm
Blade tilt
0–45 degrees
Main motor
3 kW
Scoring blade
120 mm, 7000–8000 rpm
Scoring motor
1.1 kW
About This Product
Rip cuts up to 1250 mm wide are made against the rip fence, while long panels travel on the sliding table for cross-cutting. The scoring saw, on its own 1.1 kW motor, marks the cut line ahead of the main blade, and the blade can be tilted to 45 degrees for bevel cuts. The Dimension Saw Machine can be dispatched from India to Mexico, Mauritius, Yemen, Belize and Sri Lanka.
Frequently Asked Questions
How wide a cut can be made against the rip fence?
The width of cut between the saw blade and the rip fence is 1250 mm; the sliding table measures 3000 x 320 mm.
What is the depth of cut?
With a 300 mm blade the height of cut is 80 mm. Blades of 250–300 mm diameter are listed, and the blade tilts from 0 to 45 degrees.
Does the machine have a scoring saw?
Yes. A 120 mm scoring saw runs at 7000–8000 rpm on a 1.1 kW motor and is adjusted by hand.
