Equipment For Studying Rotational Motion Manufacturer,Supplier and Exporter in India
Product Code : EL-TWL-11801
Quick Answer: Equipment For Studying Rotational Motion is a turning-platform system for experiments on centrifugal force, angular momentum and rotational inertia, with a 23 cm disk, a ring and a 24 V, 1500 rpm DC motor for continuous rotation. Adapters let sensors follow angular position, speed and acceleration.
Last updated: October 2026
Key Features
Turning platform with 22 x 22 cm base support and 51 x 4 cm track.
Disk of 23 cm diameter and ring of 12.5 cm outer, 10.5 cm inner diameter.
2 trucks, one mobile and one steady.
DC motor, 24 V, 1500 rpm, mounted on a support for continuous rotation.
Adapters for angular position, speed and acceleration sensors.
Pulley and rod, chronometer, springs, masses and accessories for centrifugal force.
Technical Specifications
| Specification | Value |
|---|---|
| Base support | 22 x 22 cm |
| Track | 51 x 4 cm |
| Disk | 23 cm diameter |
| Ring | 12.5 cm outer, 10.5 cm inner diameter |
| Trucks | 2 (1 mobile, 1 steady) |
| Motor | DC, 24 V, 1500 rpm |
About This Product
The training programme covers conservation of angular momentum with a mass point, with the disk and ring, and in a projectile version, along with rotational inertia of a mass point, of a disk and a ring about two axes, and of a fixed or turning offset disk. Differences in moment of inertia are large enough for students to feel even when they turn the system by hand. The accessories also support tests on couple and friction.
Frequently Asked Questions
Which experiments does the training programme include?
Conservation of angular momentum (mass point, disk and ring, projectile version), rotational inertia of a mass point, of a disk and ring about two axes and of an offset disk, and centrifugal force.
Can the platform be driven continuously?
Yes. A 24 V DC motor rated at 1500 rpm connects to a support to give continuous rotation; the system can also be turned by hand.
Related: Training Workshop Labs, Equipment For Studying Centrifugal Force, Acceleration Sensor, Apparatus for the Study of Harmonic Oscillations.
For a quotation on the Equipment For Studying Rotational Motion, contact Educational Lab Equipments.
