Drilling Tool Manufacturer,Supplier and Exporter in India
Product Code : EL-TOMLE-11880
Quick Answer: The Drilling Tool is an arm wheel type strain gauge drill tool dynamometer that measures thrust and torque while a hole is being drilled. It handles holes up to 25 mm in mild steel and shows both values together on a two-channel digital indicator.
Last updated: October 2026
Key Features
Arm wheel type sensing unit with strain gauges, combined with a work piece holder.
Measures thrust and torque simultaneously.
Compact two-channel digital force indicator with balancing potentiometer.
Suitable for drilling holes up to 25 mm in mild steel.
Cutting fluid can be used during drilling.
Calibrated at the factory using a proving ring, with readings directly in kg.
Technical Specifications
Specification
Value
Type
Arm wheel, strain gauge drill tool dynamometer
Quantities measured
Thrust and torque
Drilling capacity
Holes up to 25 mm in mild steel
Indicator
2-channel digital, balancing potentiometer
Panel
Switches, fuses, screen-printed front plate, connecting cables
Readout
Directly in kg, calibrated with a proving ring
About This Product
Here the workpiece is held on the strain-gauged sensing unit, so the thrust and torque it feels during drilling are passed straight to the control panel. By repeating holes at different speeds, depths and feeds, students can see how each change alters the two readings. A sensitive amplifying system supports accurate force measurement, and cutting fluid may be applied as in normal drilling.
Frequently Asked Questions
What does the Drilling Tool measure?
Thrust and torque during a drilling operation, both shown at the same time on the two-channel digital force indicator.
What hole size can it take?
It is suitable for drilling holes up to 25 mm in mild steel.
How is it calibrated?
The dynamometer is calibrated at the factory with a proving ring, and its readings are given directly in kg.
