CBR Test Machine Hand Operated Manufacturer,Supplier and Exporter in India
Product Code : EL-SM-11897
Quick Answer: The CBR Test Machine Hand Operated is a 5000 kg hand-operated load frame with high and low rates of travel, supplied with a 150 mm mould, penetration piston, surcharge weights and rammers for laboratory CBR tests. The proving ring and dial gauge are not included.
Last updated: October 2026
Key Features
Hand-operated load frame, 5000 kg capacity, with high and low load screw travel rates.
Gun-metal/brass mould 150 mm internal diameter x 175 mm high, with perforated base plate and 50 mm extension collar.
Penetration piston, 50 mm face diameter, with adjustable dial gauge bracket.
Spacer disc 148 mm diameter x 47.7 mm high with detachable handle.
Annular and slotted surcharge weights, 2.5 kg each, 147 mm diameter with 53 mm hole or slot.
Gun-metal/brass perforated plate with adjustable stem and lock nut, plus metal tripod for the dial gauge.
Technical Specifications
| Specification | Value |
|---|---|
| Load frame | Hand operated, 5000 kg |
| Mould | 150 mm ID x 175 mm high, gun-metal/brass |
| Extension collar | 50 mm high |
| Penetration piston | 50 mm face dia |
| Spacer disc | 148 mm dia x 47.7 mm |
| Surcharge weights | 2.5 kg annular and 2.5 kg slotted, 147 mm dia |
| Rammers | 2.6 kg with 310 mm drop; heavier rammer with 450 mm drop |
About This Product
Soil specimens are compacted in the mould with the 2.6 kg rammer at a 310 mm drop or the heavier rammer at a 450 mm drop, then tested on the frame as the piston is driven in under surcharge weights. The operator applies penetration by hand using the fast or slow travel of the load screw; the proving ring and dial gauge needed to read load and penetration are not part of the supply. Colleges and TVET centres in Samoa, Qatar, South Africa, Bahrain, United Kingdom and Lithuania can source the CBR Test Machine Hand Operated from Educational Lab Equipments.
Frequently Asked Questions
Are a proving ring and dial gauge included with the CBR Test Machine Hand Operated?
No. The machine is supplied without a proving ring and dial gauge.
What is the capacity of the load frame?
The hand-operated load frame has a capacity of 5000 kg, with high and low rates of travel of the load screw.
What mould is supplied?
A gun-metal/brass mould of 150 mm internal diameter and 175 mm height, with a perforated base plate and a 50 mm extension collar.
Related: Soil Mechanics, Motorised CBR Machine, Field CBR Equipment, Automatic Mechanical Soil Compactor.
For a quotation on the CBR Test Machine Hand Operated, contact Educational Lab Equipments.
