Digital Point Load Tester Manufacturer,Supplier and Exporter in India
Product Code : EL-CL-11892
Quick Answer: The Digital Point Load Tester determines the strength of rock specimens in the field or the laboratory, loading cores up to 101.6 mm (4 in) diameter between two conical points. A manual hydraulic jack on the load frame applies up to 56 kN, read on a digital load cell display.
Last updated: October 2026
Key Features
Load frame for loads up to 56 kN with a manual hydraulic jack.
Accepts core specimens up to 4 in (101.6 mm) diameter.
Graduated scale shows the distance between the conical points.
Electric load cell with digital display, 0–56 kN, 65,000 divisions, 0.001 kN resolution.
Linearity 0.05%, hysteresis 0.03%, repeatability 0.02%.
Supplied in a wooden carrying case with goggles and accessories.
Technical Specifications
| Specification | Value |
|---|---|
| Load capacity | 56 kN |
| Specimen size | Cores up to 101.6 mm (4 in) dia |
| Display | Digital, 0–56 kN, 65,000 divisions |
| Resolution | 0.001 kN |
| Linearity / hysteresis / repeatability | 0.05% / 0.03% / 0.02% |
| Dimensions | 400 x 530 x 720 mm |
About This Product
With the specimen held between the two cones, the operator applies load through the hydraulic jack while the load cell display shows the force and the graduated scale shows the point spacing. The strength index is found by dividing that load P by the square of D, the distance between the conical points. The wooden carrying case suits work in the field as well as in the laboratory. Educational Lab Equipments can supply and export the Digital Point Load Tester to Malta, Malawi, Togo, Egypt and Gambia.
Frequently Asked Questions
How is the point load strength index worked out?
The index is given by P divided by D squared, where P is the value from the load cell and D is the distance between the two conical points, read on the graduated scale.
What specimen sizes does the Digital Point Load Tester accept?
Core specimens up to 4 in (101.6 mm) in diameter, loaded between two cone-shaped points.
What is supplied with it?
A wooden carrying case, goggles and accessories. The tester measures 400 x 530 x 720 mm.
Related: Concrete Laboratory, Motorized Compression/Tension Machine, Impact Testing Machine, Concrete Cover Meter.
