Static and Dynamic Balancing Apparatus Manufacturer,Supplier and Exporter in India
Product Code : EL-TOMLE-11867
Quick Answer: The Static and Dynamic Balancing Apparatus is used to balance a rotating mass system: four blocks clamp onto a stainless steel shaft held in a rectangular frame, and a variable-speed motor spins the shaft to check dynamic balance.
Last updated: October 2026
Key Features
Stainless steel shaft fixed in a rectangular frame.
Set of four stainless steel blocks with different eccentric masses and a clamping arrangement.
Cord and container system using steel balls to find each block's relative weight.
Angular and longitudinal scales for positioning the blocks.
Frame suspended on chains for dynamic balancing.
FHP variable-speed drive motor with speed controller.
Technical Specifications
Specification
Value
Shaft
Stainless steel
Balancing weights
4, stainless steel, different eccentric masses
Drive motor
FHP, variable speed, with speed controller
Scales
Angular and longitudinal
Electricity
0.5 kW, 220 V, single phase
About This Product
For static balancing, each block is clamped on the shaft in turn and its relative weight is measured in steel balls with the cord and container. For dynamic balancing, those relative weights are used to draw a moment polygon that gives the angular and axial positions of the blocks, and the motor then runs the shaft to confirm the balance. The same set-up shows the effect of unbalance in a rotating mass system. Colleges and TVET centres in Chad, Mongolia, Mauritania, Togo and Libya can source the Static and Dynamic Balancing Apparatus from Educational Lab Equipments.
Frequently Asked Questions
How is a block's relative weight measured?
Each block is clamped on the shaft on its own and its relative weight is found with a cord and container system, counted in steel balls.
