Panel Meters Manufacturer,Supplier and Exporter in India
Product Code : EL-PLE-10314
Quick Answer: Panel Meters are pointer meters for fitting into a panel, offered in round, square and rectangular cases with scale lengths from 50 mm to 85 mm. Every version has a knife-edge pointer and an accuracy of +/-2 FSD.
Last updated: October 2026
Key Features
Round type: moulded black ABS plastic case, 50 mm scale, about 80 mm round overall.
Square type: clear transparent case on a white ABS base, 50 mm scale, 65 x 65 mm.
Larger square type: same case style, 60 mm scale with anti-parallax mirror, 80 x 80 mm.
Rectangular type: moulded black ABS plastic case with clear front window, 85 mm scale, 80 x 100 mm.
Knife-edge pointer, with or without anti-parallax mirror scale on the other types.
Accuracy +/-2 FSD.
Technical Specifications
| Specification | Value |
|---|---|
| Round type | Black moulded ABS case; 50 mm scale; 80 mm round |
| Square type, 65 x 65 mm | Clear case, white ABS base; 50 mm scale |
| Square type, 80 x 80 mm | Clear case, white ABS base; 60 mm scale, anti-parallax mirror |
| Rectangular type | Black moulded ABS case, clear front window; 85 mm scale; 80 x 100 mm |
| Pointer | Knife edge |
| Accuracy | +/-2 FSD |
About This Product
The four case styles let a meter be chosen to fit the space available on a panel, from the compact 65 mm square to the 80 x 100 mm rectangular body. Where a mirror scale is fitted, lining the pointer up with its reflection removes parallax from the reading. The Panel Meters can be dispatched from India to Timor-Leste, Montenegro, Brazil, South Sudan, Bolivia and Dominican Republic.
Frequently Asked Questions
Which panel meter shapes are available?
Round (about 80 mm), square in 65 x 65 mm and 80 x 80 mm, and rectangular (80 x 100 mm).
Do the panel meters have an anti-parallax mirror?
The 80 x 80 mm square type has an anti-parallax mirror scale. The round, 65 x 65 mm square and rectangular types are offered with or without one.
What accuracy do the panel meters have?
Each type is specified at +/-2 FSD, with a knife-edge pointer.
Related: Physics Lab Equipments, Ballistic Galvanometer.
For a quotation on the Panel Meters, contact Educational Lab Equipments.
