Spray Tower Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11368
Quick Answer: The Spray Tower is a glass-column set-up for demonstrating spray extraction and mass transfer, run continuously with rotameters for flow and an adjustable interface zone height.
Last updated: October 2026
Key Features
Glass column with feed tanks, receiving trays and piping.
Rotameters for flow measurement.
Air regulator with pressure gauge; runs on clean, oil- and moisture-free compressed air at 2 Bar.
Special arrangement for changing the height of the interface zone.
Continuous operation; stainless steel tanks and wetted parts.
Technical Specifications
Specification
Value
Column
Glass
Flow measurement
Rotameters
Compressed air
2 Bar, clean, oil and moisture free
Electric supply
230 +/- 10 VAC, 50 Hz, single phase, earthed
Compressor socket
5 A, three pin, with switch
About This Product
The tower lets students run a spray extraction continuously in a glass column and watch the mass transfer taking place. Flow rates are set and read on the rotameters, and the interface zone can be raised or lowered to see how its height changes the operation.
Frequently Asked Questions
What does the spray tower demonstrate?
The principles of spray extraction and of mass transfer operation in a column, with continuous running in a glass column.
What services are needed?
Clean, oil- and moisture-free compressed air at 2 Bar; a 230 +/- 10 VAC, 50 Hz single-phase earthed supply with a 5 A three-pin switched socket for the compressor; and water supply and drain.
Can the interface position be changed?
Yes, a special arrangement allows the height of the interface zone to be changed.
