Sensors Trainer Captech Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11256
Quick Answer: The Sensors Trainer Captech pairs an aluminium-section operative part – a tray with 4 notches and a dual-belt conveyor – with a separate control desk, so students can test sensors of different technologies on moving boxes.
Last updated: October 2026
Key Features
Operative part in aluminium section for a working table, with a 4-notch tray driven by a 24V gear motor.
Dual-belt conveyor 150 mm wide: a 1500 mm first belt for small boxes and boxes of materials other than iron, and a 1000 mm second belt for big boxes, with a 220V gear motor.
Switch gear between the two belts, moved by its own 24V gear motor.
Sensors of different technologies plus additional deficient sensors, with desk switches that simulate the sensors.
Control desk with a 3-position connection selector, key-operated emergency stop, green cycle-start and black cycle-end illuminated push-buttons and a 2-position drainage switch.
Operator dialogue terminal, 220V/24V transformer, motor circuit breaker and contactor, and an ON/OFF switch with 220V power cable.
Technical Specifications
| Specification | Value |
|---|---|
| Conveyor belt width | 150 mm |
| Belt 1 length | 1500 mm (small boxes, materials other than iron) |
| Belt 2 length | 1000 mm (big boxes) |
| Gear motors | 24V for tray and switch gear; 220V on the conveyor |
| Control transformer | 220V / 24V |
| Connection types | AS-i, terminal or connector sockets, by 3-position selector |
| Construction | Aluminium section, for a working table |
About This Product
Boxes ride the conveyor while the notched tray and the switch gear route them, giving sensors of several technologies real objects to detect, including boxes made of something other than iron on the first belt. From the control desk the class picks how the sensors are wired, starts and ends the cycle, and uses switches in place of sensors, while the extra deficient sensors give faults to trace. Technical documentation and an electric diagram come with the operative part. Colleges and TVET centres in Malaysia, Cabo Verde, Portugal, Kenya and Paraguay can source the Sensors Trainer Captech from Educational Lab Equipments.
Frequently Asked Questions
How long are the conveyor belts on the Sensors Trainer Captech?
Both belts are 150 mm wide. The first belt is 1500 mm long and handles small boxes and boxes made of materials other than iron; the second is 1000 mm long and is meant for big boxes.
Which sensor connection types can be selected?
A rotary button on the control desk has 3 positions, one for each type of connection: AS-i, terminal, or the connector-type sockets fitted on the desk.
Can sensor faults be simulated?
Yes. The desk has switches that simulate the sensors, and the operative part comes with additional deficient sensors alongside the sensors of different technologies.
