Resistance Box Decade Dial Type Manufacturer,Supplier and Exporter in India
Product Code : EL-PLE-10277
Quick Answer: The Resistance Box Decade Dial Type uses four click-stop dials, each with 10 resistances, to set values in 1 ohm steps up to a total of 11.11 kilohms, with an accuracy of plus or minus 5%.
Last updated: October 2026
Key Features
Four decade dials: 0–10 ohm in 1 ohm steps, 0–100 ohm in 10 ohm steps, 0–1000 ohm in 100 ohm steps and 0–10 kilohm in 1 kilohm steps.
Knob on each dial turns with a positive click stop against an index mark.
Dials connected in series, giving a total resistance of 11.11 kilohms.
Pair of 4 mm sockets for the circuit and a yellow earthing socket.
Dials sit under a metal cover plate in an aluminium extrusion case.
Accuracy plus or minus 5%.
Technical Specifications
Specification
Value
Decade dials
4
Steps per dial
10 resistances
Ranges
0–10 ohm x 1 ohm, 0–100 ohm x 10 ohm, 0–1000 ohm x 100 ohm, 0–10 kilohm x 1 kilohm
Total resistance
11.11 kilohms
Accuracy
+/-5%
Terminals
2 x 4 mm sockets, yellow earth socket
Case
Aluminium extrusion, metal cover plate
About This Product
Turning the knobs dials in a resistance directly, without plugs, and because the dials are wired in series their settings add to give the total in the circuit. The click stops make each value easy to set and to read back from the index mark. Colleges and TVET centres in Guinea-Bissau, Sudan, Mexico, Malta, Albania and Mongolia can source the Resistance Box Decade Dial Type from Educational Lab Equipments.
Frequently Asked Questions
What is the total resistance of the Resistance Box Decade Dial Type?
With all four decade dials in series, the total is 11.11 kilohms. The dials step in units of 1, 10, 100 and 1000 ohms.
How is it connected?
A pair of 4 mm sockets connects the resistance across a circuit, and a yellow socket is provided for earthing.
