Force Table Manufacturer,Supplier and Exporter in India
Product Code : EL-PLE-10872
Quick Answer: The Force Table is a machined aluminium table, 40 cm in diameter, with an engine-divided 360-degree scale on its raised rim, used in experiments on the composition and resolution of forces.
Last updated: October 2026
Key Features
Machined aluminium table, 40 cm in diameter.
Raised rim carrying an engine-divided scale graduated through 360 degrees.
Mounted on a heavy vertical support rod with a tripod base.
4 sliding clamp pulleys and 4 weight hangers.
1 ring and 12 weights: 2 x 10 g, 2 x 20 g, 4 x 50 g and 4 x 100 g.
Technical Specifications
Specification
Value
Table
Machined aluminium, 40 cm dia.
Scale
Engine divided, 360 degrees, on raised rim
Support
Heavy vertical rod, tripod base
Pulleys
4 sliding clamp pulleys
Weight hangers
4
Weights
12 (2 x 10 g, 2 x 20 g, 4 x 50 g, 4 x 100 g)
Ring
1
About This Product
Students clamp the pulleys at chosen points round the rim, load the hangers with weights and find the arrangement that holds the ring in balance. Reading the angles from the 360-degree scale lets them check the result against the laws of composition and resolution of forces. The Force Table can be dispatched from India to Saint Lucia, Haiti, Jamaica, Bahrain, Brunei and Iceland.
Frequently Asked Questions
What is supplied with the Force Table?
1 ring, 4 sliding clamp pulleys, 4 weight hangers and 12 weights: 2 x 10 g, 2 x 20 g, 4 x 50 g and 4 x 100 g.
What is the table made of?
Machined aluminium, 40 cm in diameter, with a raised rim carrying a 360-degree engine-divided scale. It stands on a heavy vertical support rod with a tripod base.
What experiments is it used for?
Experiments on the laws of composition and resolution of forces.
