Digital Meter Manufacturer,Supplier and Exporter in India
Product Code : EL-PLE-10315
Quick Answer: The Digital Meter is a desk-stand DC meter with a three-and-a-half-digit LCD, 13 mm high, powered by a 9 volt battery. It is offered in DC ammeter ranges from 199.9 microamps to 19.99 A and DC voltmeter ranges from 199.9 mV to 500 V.
Last updated: October 2026
Key Features
Desk-stand design for general laboratory use.
Three-and-a-half-digit LCD with 13 mm high digits.
Runs on a 9 volt battery.
Typical accuracy +/-0.3% and typical linearity 0.2%.
DC ammeter ranges: 199.9 microamps, 1.999 mA, 19.99 mA, 199.9 mA, 1.999 A and 19.99 A.
DC voltmeter ranges: 199.9 mV, 1.999 V, 19.99 V, 199.9 V and 500 V.
Technical Specifications
Specification
Value
Display
LCD, three and a half digit, 13 mm digit height
Power
9 V battery
Accuracy
+/-0.3% typical
Linearity
0.2% typical
DC ammeter ranges
199.9 microamps, 1.999 mA, 19.99 mA, 199.9 mA, 1.999 A, 19.99 A
DC voltmeter ranges
199.9 mV, 1.999 V, 19.99 V, 199.9 V, 500 V
About This Product
Set on its desk stand, the meter shows current or voltage as a direct numerical reading, so students record values without interpolating between scale marks. Separate DC current and voltage ranges let a lab keep a meter matched to each part of its circuit work. The Digital Meter can be dispatched from India to Moldova, Indonesia, Iceland, Saint Lucia, Belize and Suriname.
Frequently Asked Questions
What power source does the Digital Meter use?
It is battery operated, from a 9 volt battery.
Which DC voltage ranges are offered?
DC voltmeter ranges of 199.9 mV, 1.999 V, 19.99 V, 199.9 V and 500 V.
How accurate is the Digital Meter?
Typical accuracy is +/-0.3%, with typical linearity of 0.2%.
