Sectional Front View Of 1PH Transformer Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11226
Quick Answer: A sectioned single-phase transformer that exposes its laminated CRGO core, wound coils, bobbins, connected leads and core assembly retainer clamps.
Last updated: October 2026
Key Features
Laminated CRGO core held by core assembly retainer clamps.
Wound coils on bobbins, with connected leads.
Insulation paper.
Base with a terminal plate marked for the connections.
Low maintenance.
Technical Specifications
Specification
Value
Type
Single phase (1PH) transformer, sectioned
Core
Laminated CRGO
Insulation
Insulation paper
Windings
Wound coils on bobbins
Terminals
Marked terminal plate on base
About This Product
With the front cut away, students can see how the coils sit on their bobbins around the laminated CRGO core and how the clamps hold the core assembly together. The terminal plate on the base is marked so each connection can be identified.
Frequently Asked Questions
What does the Sectional Front View Of 1PH Transformer show?
Its laminated CRGO core, core assembly retainer clamps, wound coils, bobbins and connected leads, along with the insulation paper, base and marked terminal plate.
What core is used?
The core is laminated CRGO, held by core assembly retainer clamps.
