Scott Connection Trainer Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11320
Quick Answer: The Scott Connection Trainer shows the main and teaser transformers of a Scott connection separately on a stand-alone panel, fed from 415 V AC +/-10%, 50 Hz. Two-phase step-down outputs are brought out for viewing the waveforms on an oscilloscope.
Last updated: October 2026
Key Features
Main and teaser transformers shown separately.
415 V AC +/-10%, 50 Hz input.
Output winding 0–230 V +/-10%, 50 Hz.
Two-phase step-down outputs for oscilloscope observation.
Stand-alone panel with on-board meters.
Extensive e-manual.
Technical Specifications
Specification
Value
Input
415 V AC +/-10%, 50 Hz
Transformers
Main and teaser, shown separately
Output winding
0–230 V +/-10%, 50 Hz
Outputs
Two-phase, step-down
About This Product
A Scott connection uses a main and a teaser transformer to obtain a two-phase output, and setting the two out separately lets students see the part each one plays. The step-down outputs can then be compared side by side on an oscilloscope.
Frequently Asked Questions
What supply does the Scott Connection Trainer need?
415 V AC +/-10% at 50 Hz.
Can the outputs be viewed on an oscilloscope?
Yes. Two-phase step-down outputs are available for observing the waveforms on an oscilloscope.
