Capacitive Load Manufacturer,Supplier and Exporter in India

Capacitive Load

Product Code : EL-EELE-11229

Quick Answer: A capacitive load housed in a powder-coated, trolley-type MS box, with capacitors connected in star with discharge resistors and switched in steps of about 1 amp.

Last updated: October 2026

Key Features

Capacitors connected in star with discharge resistors.

Load varied in steps of approximately 1 amp using rotary switches.

Ammeter and voltmeter for current and voltage at different loads.

Trolley-type MS box, powder coated.

Technical Specifications

SpecificationValue
ConnectionStar, with discharge resistors
Step sizeApprox. 1 A, via rotary switches
MeteringAmmeter and voltmeter
HousingTrolley-type MS box, powder coated

About This Product

Turning the rotary switches adds capacitance in steps of roughly 1 amp, while the ammeter and voltmeter record the current and voltage at each load. The capacitors are wired in star together with discharge resistors, and the whole unit sits in a powder-coated MS box on a trolley.

Frequently Asked Questions

In what steps can the Capacitive Load be varied?

In steps of approximately 1 amp, selected with rotary switches.

How are the capacitors connected?

They are connected in star, together with discharge resistors.

Related: Electronics Engineering Lab Equipments, Inductive Load Banks, Resistive Load Banks, Load Test On 1 PH Transformer Panel.

For a quotation on the Capacitive Load, contact Educational Lab Equipments.
