ATM Demonstrator Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11300
Quick Answer: The ATM Demonstrator is a training system for the basic concepts of an ATM, with a 16 x 2 character LCD, a 4 x 3 key matrix and PIC16F877A and PIC16F84A microcontrollers. It runs from 6 V DC and links to a PC over RS-232.
Last updated: October 2026
Key Features
16 x 2 character LCD.
4 x 3 key matrix for entry.
PIC16F877A and PIC16F84A microcontrollers.
RS-232 (DB-9) PC interface.
Test points for study, plus an extensive manual.
Technical Specifications
Specification
Value
Display
16 x 2 character LCD
Microcontrollers
PIC16F877A, PIC16F84A
Input
6 V DC
PC interface
RS-232 (DB-9)
Key matrix
4 x 3
About This Product
The demonstrator breaks ATM technology into parts students can examine: a keypad for entry, an LCD for prompts, microcontrollers for control and a serial link to a PC. Test points along the circuit and an extensive manual support study of each part. Educational Lab Equipments can supply and export the ATM Demonstrator to Mozambique, Democratic Republic of the Congo, Malaysia, Lithuania and Jordan.
Frequently Asked Questions
Which microcontrollers does the ATM Demonstrator use?
It uses the PIC16F877A and PIC16F84A.
How does it connect to a computer?
Through an RS-232 PC interface with a DB-9 connector.
